Surface Mount MOX Divider - MC1RD Series

MC1RD Series

Surface Mount SMT-MOX Divider

High Voltage/High Resistance

Ohmite’s MC1RD resistors bring precision high voltage capabilities to surface mount applications. Designed with thick film on alumina substrate technology, the resistors can be provided in ratios down to 0.5% with custom configurations available. The planar package design is low profile for easy use with instrumentation, medical equipment, voltage regulators, and power supplies.

SMT-MOX Divider Features:

  • "J" terminal 0.018" wide tin-plated copper
  • Thick film on alumina
  • Wattage: 1.5W
  • Ratio TCR: 100ppm; 25ppm, and 10ppm available
  • Ratio Tolerance 0.5% to 5%
