S Series Datasheet

Terminal Type:

DIN

Construction:

Plate

Rated Current:

100

Voltage(mV):

60

Accuracy Class:

0.50%

Terminal Type:

T

Construction:

Plate

Rated Current:

250

Voltage(mV):

60

Accuracy Class:

0.50%

Terminal Type:

L

Construction:

Plate

Rated Current:

600

Voltage(mV):

60

Accuracy Class:

0.50%

Terminal Type:

L

Construction:

Plate

Rated Current:

1200

Voltage(mV):

60

Accuracy Class:

0.50%

Terminal Type:

DIN

Construction:

Plate

Rated Current:

100

Voltage(mV):

75

Accuracy Class:

0.50%

Terminal Type:

T

Construction:

Plate

Rated Current:

200

Voltage(mV):

75

Accuracy Class:

0.50%

Terminal Type:

T

Construction:

Plate

Rated Current:

500

Voltage(mV):

75

Accuracy Class:

0.50%

Terminal Type:

L

Construction:

Plate

Rated Current:

1000

Voltage(mV):

75

Accuracy Class:

0.50%

Terminal Type:

T

Construction:

Plate

Rated Current:

500

Voltage(mV):

100

Accuracy Class:

0.50%

Acid Wash and Passivation

Acid Wash and Passivation

Null Balance Resistance Bridge

GB/T7676-1998 (Direct acting indicating analog electrical measuring instruments and their accessories)

IEC610101-1: 1890 (Safety requirements for electrical equipment for mea-surement, control, and laboratory use-Part I: General requirements)

SJ/T11363-2006 (Requirements for concentration limits for certain hazard-ous substances in electronic information products)

linearly from 25°C to 85°C
