CSM Series Datasheet

Surface Area(in2 / mm2):

1.84 / 1,188

Weight(oz / g):

0.13/ 3.7

Length L(mm):

12

ThermalRes.*(°C/W):

18.0

Surface Area(in2 / mm2):

4.30 / 2,772

Weight(oz / g):

0.3 / 8.5

Length L(mm):

28

ThermalRes.*(°C/W):

12.8

Surface Area(in2 / mm2):

6.14 / 3,960

Weight(oz / g):

0.43 / 12.2

Length L(mm):

40

ThermalRes.*(°C/W):

12.1

Surface Area(in2 / mm2):

6.25 / 4,029

Weight(oz / g):

0.5 / 14.2

Length L(mm):

30

ThermalRes.*(°C/W):

11.3

Surface Area(in2 / mm2):

10.30 / 6,645

Weight(oz / g):

0.6 / 17.00

Length L(mm):

50

ThermalRes.*(°C/W):

9.8

Aluminum Alloy 6063-T5 or Equivalent with either degreased or black anodized finish.

Cold-rolled Steel, surface tin plated.

for improvement, use thermal joint compound, 0.005 Grafoil (TGon 800 by Laird), or phase change material (Hi-Flow by Bergquist)

(Optional) Sil-Pad 900-S, K6 800-S and K10 by Bergquist
