10 Series

10 Series

Axial Wire Element Current Sense

Two and Four Terminal Axial

Ohmite’s 10 series current sense resistors are available in a standard two terminal axial and a four-terminal kelvin design. 1% tolerances are standard with a fixed measuring point. The element design is non-inductive be low at 0.25 ohms. Ohmite’s Four-terminal Current-sense design is specifically designed for low-resistance applications requiring the highest accuracy and temperature stability. This four-terminal version of Ohmite’s 10 Series resistor is specially designed for use in a Kelvin configuration, in which a current is applied through two opposite terminals and sensing voltage is measured across the other two terminals.
