Product Change Notice

89 Series Resistors Dimensional Changes
Effective date: 1 August 2015

Ohmite announces dimensional changes to the 89 series of resistors. These changes are reflected on the mounting tabs and extrusion profiles. Foot design changes are from the (Old) rounded foot design to a (New) squared design. The changes are also seen in the extrusion profile. These changes have no effect on Fit, Form or Function of the parts. All new parts can be mounted in existing applications with no modifications. Part numbering will not change. Images not to scale. Details
